MTB Zenith Team

MTB Zenith Team 150 150 PROTOTYPE

Zenith Team

Our top aluminum range!

A wheel designed for customers who love aluminium wheels, but with very unique details and features.

Is your all out cross country wheelset!

Provide the greatest performance that an aluminium wheel can provide, wide and light, developed in the hardest cross country tracks in the world.

HUB Detail
RIM Detail

MSRP: 840 €

SPECIFICATIONS

Rim

  • Material: aluminium
  • Width (inner/outer): 25/28mm
  • Profile: 16mm
  • Type: tubeless ready
  • Rim shape: hookless

Hub

  • Model: EVO 4
  • Material: Aluminium light-force
  • Bearings: sealed – PROTOTYPE PRO 2
  • Braking System: IS (6-bolt)
  • Clamping: thru-axle

Tire

  • Size: 29″
  • Type: tubeless or tubeless ready
  • Width: 2.0 to 2.2
  • Max. Pressure: 60psi /4bar

Spokes and Nipples

  • Model: aero SL 2.0
  • Type: J bend
  • Spoke material: sandvik
  • Nipple material: aluminium

Compatibility Wheel

  • Front Wheel
  • Caps: 15x110mm (Hub EVO 4 110)
  • Caps: 9x100mm/ 15x100mm (Hub EVO 3.1)
  • Hub: Lefty / Lefty Supermax
  • Rear Wheel
  • Caps: 12x148mm (Hub EVO 4 148)
  • Caps: 10x135mm/ 12x142mm (Hub EVO 3.1)

Options

  • Front caps: Fox or Rock Shox
  • Freweel body options: Shimano 11, Sram XD or Micro Spline
  • Ceramic bearings: yes
  • Color: sticker

Wheelset and weight

  • Discipline: XC
  • ASTM: 3 – ASTM List
  • Weight limit: 85kg
  • Weight (29″ boost): 1490gr

  • Include accessories: user manual, UST Rim tape, aluminium valves

Note: The weights indication is just a reference value.
