MTB Carbon Team

MTB Carbon Team 150 150 PROTOTYPE

Carbon Team

A model with a great legacy of the past!

The upgrade of the bronze medal wheels at the Rio 2016 Olympic Games. With the difficult goal of improving the multi-award winning Carbon Team wheels, Prototype’s technical development team raised the bar again by making the wheels even more responsive with the new 30mm wide asymmetric, hookless full carbon and tubeless ready rim. These wheels were tested by BH’s factory team at the UCI World Cup for a season to optimize all wheel characteristics.

HUB Detail
RIM Detail

MSRP: 1.490 €

Carlos Coloma has proven the quality and reliability of PROTOTYPE products, the world Bronze medal was the result …

  • Bronze Medal Rio 2016
  • Two podiums in UCI World Cup
  • Twice Spanish XCO Champion

Performance and reliability are our main concerns.

Weighing just 1420gr, the Carbon Team helps you accelerate with astonishing speed and climb steep hills with less effort.

The full carbon rims asymmetric have the perfect balance of lateral stiffness and just enough compliance to take the edge off roots, rocks and ruts on the track.

More rigid, lighter, more accurate and easy to maintain.

The new Carbon Team wheel has the legacy of an already winning wheel, improving a product with such results is a task up to Prototype’s technical team. Further enhanced with the redesigned freehub system that can transfer greater pedaling power, resulting in a more direct transmission of power. Oversized bearings increase smooth and long-lasting operation maintain lightness, rigidity and durability.

KEY BENEFITS

Use every inch of the track!

Accelerate, corner and sprint faster with lighter, stiffer wheels.

All the details make the difference.

Built wide (25mm internal), they are optimized to squeeze the most performance out of 2.1″ to 2.30″ XC tires.
If you’re looking for a way to supercharge your XC bike, this carbon wheel adds performance you can feel.

With full carbon rim and all of our latest off-road technologies, these wheels deliver superior performance to make you feel like a real high level athlete.

The J-Blend 2.0 aero spokes makes it possible to increase wheel stiffness by 9%, providing excellent performance that will surely surprise you!

SPECIFICATIONS

Rim

  • Material: full carbon
  • Width (inner/outer): 25/30mm
  • Profile: 26mm
  • Type: tubeless ready
  • Rim shape: hookless

Hub

  • Model: EVO 4
  • Material: Aluminium light-force
  • Bearings: sealed – PROTOTYPE PRO 2
  • Braking System: IS (6-bolt)
  • Clamping: thru-axle

Tire

  • Size: 29″
  • Type: tubeless or tubeless ready
  • Width: 2.0 to 2.5
  • Max. Pressure: 60psi /4bar

Spokes and Nipples

  • Model: aero 2.0
  • Type: J bend
  • Spoke material: sandvik
  • Nipple material: aluminium

Compatibility Wheel

  • Front Wheel
  • Caps: 15x110mm (Hub EVO 4 110)
  • Caps: 9x100mm/ 15x100mm (Hub EVO 3.1)
  • Hub: Lefty / Lefty Supermax
  • Rear Wheel
  • Caps: 12x148mm (Hub EVO 4 148)
  • Caps: 10x135mm/ 12x142mm (Hub EVO 3.1)

Options

  • Front caps: Fox or Rock Shox
  • Freweel body options: Shimano 11, Sram XD or Micro Spline
  • Ceramic Bearings: yes
  • Color: white or black

Wheelset and weight

  • Discipline: XC
  • ASTM: 3 – ASTM List
  • Weight limit: 90kg
  • Weight (29″ boost): 1420gr

  • Include accessories: user manual, UST Rim tape, aluminium valves

Note: The weights indication is just a reference value.
